Zebra / Javelin 塑膠卡片打印機
J110i J120i J330i J420 J430i

J110i

Zebra 最經濟的彩色單面膠卡打印機

可靠、緊湊、操作簡便的J110i打印機，是Zebra公司推出
的一款最具可購性的彩色卡片打印。它設計精巧，使用高
強度塑料和高級電子部件，具有小型、輕質、性能卓越和
價格低廉等優點。J110i可提供始終如一的優質打印，同
Zebra的其它產品一樣，具有值得信賴的可靠性。


產品手冊 (PDF) 例行清潔示範
(WMV)
安裝卡片示範
(WMV)		 安裝色帶盒示範
(WMV)

經濟實惠

．

 低初始投資

．

 符合直覺式的設計簡化了安裝過程，降低了培訓成本


操作簡便
．
 Load-N-Go™ 色帶盒，安裝簡便
．
 i Series 色帶自動檢測功能，能夠讓打印機配置出最優化的圖像，
並安裝有色帶量過低報警指示，操作起來更加方便
．
 便於閱讀的16位LCD可顯示操作和定期清潔信息

．

 藍色觸點為用戶指示可觸式功能


性能可靠

．

 使用專利技術，用高強度塑料製成，配備先進的電子部件。
不但提供可靠的性能，而且降低維護成本

．

 可選磁帶編碼 (HiCo/LoCo)


更多功能

．

 全色或單色打印

．

 自動進卡或CardSense™ 單張進卡

．

 3磁道HiCo/LoCo編碼器，可以選擇上/下磁帶編碼

．

 精巧、緊湊、輕質的設計適用於各種環境



Load-N-Go™ 色帶盒
．
 Load-N-Go™ 色帶盒內置卡片清潔軸，
更換簡便


產品規格
一般規格

» Load-N-Go™ 插入式色帶盒
» 16-字元 LCD 顯示螢幕
» 提供Window® 2000/XP 驅動程式
彩色列印

» 染色昇華/樹脂熱轉印
» 30秒一張彩色單面列印(YMCKO)
» 300 dpi (11.8 dots/mm) 高解析度列印

條碼種類

» Code 39, Code 128 B & C (帶或不帶驗核碼)
» 2 of 5 & 2 of 5 Interleaved
» UPC-A, EAN 8 & EAN 13
» 可通過Windows 驅動程式打印 PDF-417 2D 條碼和其它條碼
傳輸介面

» USB 1.1 (支援USB 2.0)
卡片規格

» 可列印PVC 卡及 合成PVC 卡
» 符合CR 80 (54 mm x 86 mm) , ISO 7810
» 磁帶標準：ISO 7811
» 接觸式或非接觸式智能卡
» 卡片厚度 : 30 mil (0.75mm ~ 0.8mm)
» 進卡槽: 100 張卡(30 mil)
» 出卡槽: 45 張卡 (30 mil)
色帶規格

» Load-N-Go™ 內置清潔軸色帶盒
» i Series ™ 色帶信息技術
» YMCKO: 200 張/盒
» 單色: 1000 張/盒 (黑色或藍色), 850 張/盒 (白色)
*為使打印機發揮最住性能，請使用原裝的 Zebra 耗材

機身規格 » 闊度: 7.9 in (201mm)
» 深度: 12.9 in (328mm)
» 高度: 8.5 in (216mm)
» 重量: 9.5 lbs (4.3kg)
電子規格 » 100 ~ 240 Volts AC, 50 ~ 60 Hz (自動)
» 8MB 圖像記憶體
» FCC Class A, CE, UL, CUL, and CCC approved
環境 » 操作溫度: 60°F to 86°F (15°C to 30°C)
» 操作濕度: 20% to 65% non-condensing
» 儲存溫度: 23°F to 158°F (-5°C to 70°C)
» 儲存濕度: 20% to 70% non-condensing
» 通風條件: 自然風
選項 » 磁卡編碼器 (適用於30 mil 磁卡), 3 磁道上/下磁帶 HiCo/LoCo
» CardSense™ 單張進卡模式
» 啟動組件 (200張 - 30 mil PVC 卡及 1 YMCKO 色帶)
» 清潔組件 (打印頭清潔卡 x 4 及進卡槽清潔卡 x 4)



J120i

僅需單面打印機的價格， 即可獲得一台
彩色雙面膠卡打印機

現在，你可以以合理的價格，獲得雙面膠卡打印功能了。Zebra J120i 打印機採用業界領先的緊緻式設計，在空間狹小的環境中，Zebra J120i 膠卡打印機是你的理想選擇，不但價格合理，更擁有雙面打印功能。

產品手冊 (PDF) 例行清潔示範
(WMV)
安裝卡片示範
(WMV)		 安裝色帶盒示範
(WMV)

經濟實惠

．

 低初始投資

．

 符合直覺式的設計簡化了安裝過程，降低了培訓成本


操作簡便
．
 Load-N-Go™ 色帶盒，安裝簡便
．
 i Series 色帶自動檢測功能，能夠讓打印機配置出最優化的圖像，並安裝有色帶量
過低報警指示，操作起來更加方便
．
 便於閱讀的16位LCD可顯示操作和定期清潔信息

．

 藍色觸點為用戶指示可觸式功能


性能可靠

．

 使用專利技術，用高強度塑料製成，配備先進的電子部件。不但提供可靠的性能，
而且降低維護成本

．

 可選磁帶編碼 (HiCo/LoCo)


更多功能

．

 全色或單色打印

．

 自動進卡或CardSense™ 單張進卡

．

 3磁道HiCo/LoCo編碼器，可以選擇上/下磁帶編碼

．

 精巧、緊湊、輕質的設計適用於各種環境



Load-N-Go™ 色帶盒
．
 Load-N-Go™ 色帶盒內置卡片清潔軸，
更換簡便


產品規格
一般規格

» Load-N-Go™ 插入式色帶盒
» 16-字元 LCD 顯示螢幕
» 提供Window® 2000/XP 驅動程式
彩色列印

» 染色昇華/樹脂熱轉印
» 40秒一張彩色雙面列印(YMCKO)
» 30秒一張彩色單面列印(YMCKO)
» 300 dpi (11.8 dots/mm) 高解析度列印
條碼種類

» Code 39, Code 128 B & C (帶或不帶驗核碼)
» 2 of 5 & 2 of 5 Interleaved
» UPC-A, EAN 8 & EAN 13
» 可通過Windows 驅動程式打印 PDF-417 2D 條碼和其它條碼
傳輸介面

» USB 1.1 (支援USB 2.0 )
卡片規格

» 可列印PVC 卡 及 合成PVC 卡
» 符合CR 80 (54 mm x 86 mm) , ISO 7810
» 磁帶標準：ISO 7811
» 接觸式或非接觸式智能卡
» 卡片厚度 : 30 mil (0.75mm ~ 0.8mm)
» 進卡槽: 100 張卡(30 mil)
» 出卡槽: 45 張卡 (30 mil)
色帶規格

» Load-N-Go™ 內置清潔軸色帶盒
» i Series ™ 色帶信息技術
» YMCKOK: 165 張/盒
» YMCKO: 200 張/盒
» 單色: 1000 張/盒 (黑色或藍色), 850 張/盒 (白色)
*為使打印機發揮最住性能，請使用原裝的 Zebra 耗材

機身規格 » 闊度: 7.9 in (201mm)
» 深度: 12.9 in (328mm)
» 高度: 8.5 in (216mm)
» 重量: 9.5 lbs (4.3kg)
電子規格 » 100 ~ 240 Volts AC, 50 ~ 60 Hz (自動)
» 8MB 圖像記憶體
» FCC Class A, CE, UL, CUL, and CCC approved
環境 » 操作溫度: 60°F to 86°F (15°C to 30°C)
» 操作濕度: 20% to 65% non-condensing
» 儲存溫度: 23°F to 158°F (-5°C to 70°C)
» 儲存濕度: 20% to 70% non-condensing
» 通風條件: 自然風
選項 » 磁卡編碼器 (適用於30 mil 磁卡), 3 磁道上/下磁帶 HiCo/LoCo
» CardSense™ 單張進卡模式
» 啟動組件 (200張 - 30 mil PVC 卡及 1 YMCKO 色帶)
» 清潔組件 (打印頭清潔卡 x 4 及進卡槽清潔卡 x 4)



J330i

High Speed , Full-Color,
High-Quality Plastic Card Printer
Has Never Been More Affordable

Easy to use and loaded with options, the J330i single-sided color card printer produces reliable and high performance printing at an affordable price.
安裝卡片示範(WMV) 安裝色帶示範(WMV)
例行清潔示範(WMV)

Ideal for



  • Access Control
    		•
  • Gift Cards
    •
  • Loyalty Cards
  • Membership Cards
    •
  • Staff Identification
  • Student Identification
    •
  • Visitor Identification
    		•

    Powerful
    Setting new standards, this single-sided, full color card printer is loaded with user-friendly features and dynamic options, which make it the most powerful and flexible printer in its class.


    Reliable
    With its new, innovative highly reliable angled feeder design (patent pending), there is simply no better choice than the J330i for mission critical applications.


    Flexible
    Designed to integrate seamlessly in a wide variety of applications, the J330i comes standard with an LCD and offers a full range of options, including build-in Ethernet.


    Zebra i Series Intelligent Printing System
    The Zebra J330i also features the benefits of enhanced Series functionality. i Series printers are designed to make card printing a simple function for all users.

    The system features:
    • Advanced RFID Technology
    • Automatic Driver Configuration
    • Intelligent Color Optimization
    • Ribbon Image Counter & Ribbon Low Notification
    • Enhanced Ribbon Formulation
    Always use TrueColours™ certified media
    SPECIFICATION
    General Specifications High speed printing
    144 cards/hour for color, single side (YMCKO)
    900 cards/hour for resin black (K)
    16MB image memory standard
    Windows™ 2000 and XP drivers
    One year printer warranty
    One year (unlimited passes) printhead warranty
    Color Printing
    		 Color dye sublimation or monochrome thermal transfer printing
    25 seconds per card full color single sided (YMCKO)
    300 dpi (11.8 dots/mm) print resolution
    Bar Codes
    		 Code 39
    Code 128 B & C with & without check digit
    2 of 5 & 2 of 5 Industrial
    UPC-A
    EAN 8 & EAN 13
    PDF-417 2D bar code and other symbologies available via Windows driver
    Fonts True Type fonts via Windows™ drivers
    Card Specifications
    		 Types: PVC, Composite PVC
    Card width/length: ISO CR-80 - ISO 7810,
    2.125" (54mm) X 3.385" (86mm)
    Option: Magnetic Stripe - ISO 7811
    Option: Smart Card - ISO 7816-2
    Card thickness: 10 mil (.25mm) to 60 mil (1.524mm)
    Card feeder capacity: 100 cards (30 mil)
    Card output hopper capacity: 100 cards (30mil)
    Optional card feeder capacity: 220 cards (30mil)
    Ribbon Specifications
    		 i Series Printers require the use of i Series ribbons for full color printing
    Monochrome: 1500 and 1000 cards/roll
    K Resin + O: 500 cards/roll
    YMCK: 400 cards/roll
    YMCKO: 200 & 330 cards/roll
    1/2 panel YMCKO: 450 cards/roll
    Overlay varnishes (clear and hologram): 350 cards/roll
    Communications Interface USB (usb cable included)
    Optional Built-in Ethernet
    Mechanical Parallel standard (parallel cable included)
    RS232C serial optional
    USB option
    Electrical 110 ~ 230 Volts AC, 50 / 60 Hz
    FCC Class A, CE, UL and CUL approved
    Environmental Quiet for offices!
    Operating Temperature: 60°F to 86°F (15°C to 30°C)
    Operating humidity: 20% to 65% non condensing
    Storage temperature: 23°F to 158°F (-5°C to 70°C)
    Storage humidity: 20% to 70% non-condensing
    Ventilation: Free air
    Options Smart card contact station (30 mil cards only)
    Built-in Ethernet
    Contactless encoding (MIFARE and HID iClass)
    High capacity feeder (220 cards)
    Magnetic encoder (20-40 mil cards only)
    Extended warranty program
    Hot Swap warranty program (USA only)
    Cleaning supplies
    Service manual


    J420i

    Dual-Sided, Edge-to-Edge Color Card Printing Is Easier and Faster Than Ever

    The J420i plastic card printer is highly versatile, and designed for high volume printing of dual-sided plastic cards in color or monochrome. Use the J420 card printer to print:

    • Employee ID, Time and Attendance cards
    • Student ID and Facilities Access Control cards
    • Club Membership and Loyalty cards

    The J420i card printer, all metal enclosure houses a low-maintenance print mechanism that includes self-cleaning card handling, high capacity ribbon system, two-line LCD control panel, and convenient card reject hopper. The reject hopper separates cards that fail encoding prior to printing, saving valuable printer ribbon. The enclosure includes a viewing window to monitor the printing process without opening the unit. Transparent input and output hoppers provide visual card capacity status.

    The J420i is easy to load and use; the operator control panel displays printer status and functions that guide the operator, using easy to understand status and simple instructions. Printer ribbon synchronization is automatic, eliminating the need for operator intervention.
    A self-cleaning cartridge thoroughly removes dust before printing to help eliminate card rejects due to dust contamination.

    Zebra card printers provide precise card printing, economical, reliable, easy-to-use operation, plus the broadest line of options, accessories and supplies in the industry.
    Zebra Plastic Card Printers are designed and
    manufactured to exacting ISO 9001:2000 standards
    for the utmost in quality and dependability, and
    sold through a worldwide network of over 100
    authorized resellers.
    Always use TrueColours™ certified media

    SPECIFICATION
    General Specifications High speed printing, over 102 cards/hour edge to edge in full color
    (YMCKO/K) throughput
    4MB image memory standard
    Standard card flip over feature for dual sided printing
    Reject card box feature
    Small footprint
    WindowsR Drivers for 95, 98, NT 4.0, 2000, ME
    One year printer warranty with Hot Swap
    One year printhead warranty (unlimited passes)
    Powerful EPCL (Eltron Printer Command Language)
    Color Printing Color dye sublimation or monochrome thermal transfer printing
    102 cards/hour throughput, 35 seconds per card, 2 sides (YMCKO/K)
    300 dpi (11.8 dots/mm) print resolution
    Edge to edge printing standard
    Bar Codes
    		 Code 39
    Code 128 B & C with & without check digit
    2 of 5 & 2 of 5 Industrial
    UPC-A
    EAN 8 & EAN 13
    PDF-417 2D bar code and other symbologies available via Windows drivers
    Fonts Resident: Arial Normal 22, Arial Bold 28
    True Type fonts available via Windows drivers
    Card Specifications
    		 Types: PVC, Composite PVC
    Card width/length: ISO CR-80 - ISO 7810, 2.125" (54mm) X 3.385" (86mm)
    Magnetic Stripe - ISO 7811
    Smart Card !V ISO 7816-2
    Card thickness: 10 mil (.25mm)3 to 60 mil (1.524mm)
    Card Feeder capacity: up to 300 cards (10 mil), up to 100 cards (30 mil)
    Card Output Hopper capacity: up to 300 cards (10 mil), up to 100 cards (30 mil)
    Ribbon Specifications Monochrome: 1500 and 1000 cards/roll
    Monochrome colors: black, red, blue, green, silver, gold, white, scratch-off grey
    K Resin + O: 500 cards/roll
    K Dye + O: 500 cards/roll
    YMCKO: 200 and 350 cards/roll
    YMCKOK: 170 cards/roll
    Overlay Varnish Specifications Thermal transfer
    Clear and holographic options available:
    - Clear - Genuine/Secure hologram
    - Pcard hologram - Custom holograms
    (various types available)
    Communications Interface
    		 Centronics Parallel standard (cable included)
    RS232C Serial port (optional)
    USB port (optional)
    Mechanical Width: 20.90" (523mm)2 Depth: 10.17" (254mm)
    Height: 10.76" (269mm) Weight: 27.5 lbs (12,5 kg)
    Electrical 110-230V, 50/60Hz
    FCC Class A, CE, UL and CUL approved
    Environmental Operating temperature: 60°F to 86°F (15°C to 30°C)
    Operating humidity: 20% to 65% non-condensing
    Storage temperature: -23°F to 158°F (-5°C to 70°C)
    Humidity: 10% to 90% non-condensing
    Ventilation: Free air
    Options RS232C Serial port
    (EPCL recommended for fast throughput)
    USB port
    Smart Card contact station (30 mil cards only)
    Magnetic encoder (30 mil cards only)
    Extended warranty program
    Hot Swap warranty program
    Cleaning supplies
    Service manual

    J430i

    High Speed , Full-Color, High-Quality Plastic Card Printing Has Never Been More Affordable

    With its LCD display and convenient user features, this rugged, dual-sided card printer readily prints high quality, personalized photo ID cards for high volume applications.

         產品手冊 (PDF)

         例行清潔示範 (WMV)
         Loading Cards Vidoe (WMV)      Loading Ribbons Vidoe (WMV)

    Ideal for



  • Access Control
    		•
  • Gift Cards
    •
  • Loyalty Cards
  • Membership Cards
    •
  • Staff Identification
  • Student Identification
    •
  • Visitor Identification
    		•



    Innovative and Easy to Use
    • Easy plug and play USB or USB with Ethernet interface simplifies configuration
    • Printhead bracket opens wide for easy ribbon access
    • 16 character LCD screen for printer status and error reporting messages
    • Translucent card cover allows you to see when supplies are running low, and blank cards can be added while printing
    • Reject bin holds cards that fail to encode correctly


    Encoding and Network Connectivity Expansion Options
    • 3 track magnetic stripe encoding (HiCo/LoCo)
    • Contact and contactless
    • Built in 10/100 Ethernet for printer networking simplifies device management and eliminates the need for third party external device


    Reliable and Flexible
    • Print dual sided or single sided
    • Revolutionary angled card feeder design means fewer rejected cards*
    • Self aligning printhead design for consistently uniform print quality


    High Performance
    • Vibrant, true-to-life colors
    • High volume card throughput
    • Large capacity card feeder available
    Always use TrueColours™ certified media


    i Series* Functionality
    • Automatic color optimization and driver configuration
    • Enhanced ribbon formulation for optimal color output
    • Ribbon image counter and ribbon low notification*
    *Patent pending

    SPECIFICATION
    General Specifications 16character LCD display
    Windows® drivers for 2000 and XP
    Bi-directional driver communication
    One year printer warranty
    Color Printing
    		 Color dye sublimation or monochrome thermal transfer printing
    102 cards per hour full color dualsided (YMCKOK)
    130 cards per hour full color singlesided (YMCKO)
    300 dpi (11.8 dots/mm) print resolution
    Bar Codes
    		 Code 39, Code 128 B & C with & without check digit
    2 of 5 & 2 of 5 Interleaved
    UPCA, EAN 8 & EAN 13
    PDF417 2D bar code and other symbologies can be printed via
    Windows drivers
    Fonts True Type fonts via Windows™ drivers
    Card Specifications
    		 Types: PVC, PVC Composite, Adhesive backed
    Card width/length: ISO CR80ISO 7810, 2.12" (54mm) x 3.38" (86mm)
    Magnetic StripeISO 7811
    Smart Card contact and contactless
    Card thickness: 10 mil (.25mm) to 60 mil (1.524mm) (+/10%)
    Card feeder capacity: 100 cards (30 mil) or 220 cards (30 mil)
    Card output hopper capacity: 100 cards (30 mil)
    Ribbon Specifications
    		 i Series™ Printers require the use of i Series ribbons for full color printing

    YMCKOK: 170 cards/roll
    YMCKO: 200 & 330 cards/roll
    1/2 Panel YMC Full KO: 450 cards/roll
    KdO: 500 cards/roll
    KrO: 500 cards/roll
    Overlay varnishes: Clear and Hologram: 350 cards/roll
    Monochrome: 1500 (Black) & 1000 cards/roll
    Monochrome colors: black, red, blue, green, silver, gold, white and
    scratch-off grey

    *for optimum printer performance use Genuine Zebra Supplies
    Communications Interface USB 1.1 (USB 2.0 compatible) cable included
    Optional Built-in Ethernet
    Mechanical Width: 26 in (660 mm)
    Depth: 9.4 in (239 mm)
    Height: 10.1 in (256 mm)
    Weight: 20 lbs (9.1 kg)
    Electrical 100 ~ 240 Volts AC, 50 ~ 60 Hz (auto switching)
    4MB image memory standard
    FCC Class A, CE, UL, CUL, and CCC approved
    Environmental Operating Temperature: 60°F to 86°F (15°C to 30°C)
    Operating Humidity: 20% to 65% non-condensing
    Storage Temperature: 23°F to 158°F (5°C to 70°C)
    Storage Humidity: 20% to 70% noncondensing
    Ventilation: Free air
    Options Builtin 10/100 Mbps Ethernet
    Smart card contact ISO 7816 encoder (30 mil cards only)
    Smart card MIFARE®/DESFire encoder (30 mil cards only)
    Magnetic encoder (30 mil cards only) 3 track HiCo/LoCo
    High capacity feeder (220 cards)
    Cleaning supplies
