| 產品規格 |
| OPERATIONAL |
| Light Source |
650 nm visible laser diode (VLD) |
| Depth of Field |
15 – 260 mm for UPC/EAN 100% |
| Scan Rate |
100 scans per second |
| Number of Scan Lines |
Single |
| Minimum Bar Width |
5 mil @ PCS 90% (0.1 mm actual) |
| Print Contrast |
30% @ UPC/EAN 100% |
| Indicators (LED) |
Three-color LED (green, red & blue) |
| Beeper Operation |
Programmable tone and beep time |
| System Interfaces |
Keyboard, RS-232C,USB 1.1, wand |
| PHYSICAL |
| Height |
165.2 mm |
| Depth |
175.1 mm |
| Width |
92.0 mm |
| Weight |
200 g (stand excluded); 563 g (stand included) |
| Cable |
Standard 2 m straight |
| ELECTRICAL |
| Input Voltage |
9V DC 1A |
| Battery |
2 AA NiMH rechargeable batteries |
| Operating Autonomy |
Over 24,000 reads at full-charged by scanning once per second |
| Recharge Time |
5 hours (max.) |
| RADIO COMMUNICATION |
| Protocol |
BluetoothR 1.2 Serial Protocol Profile (SPP) |
| Radio Frequency |
2.4 – 2.48 GHz |
| Working Range |
Class 1 up to 100 m / 75 m (depends on operating environment) |
| REGULATORY |
| Laser Class |
CDRH Class II; IEC 60825-1: Class 1 |
| EMC |
CE & FCC DOC compliance |
| Radio |
FCC TCB, EN 300 328, ARIB STD-T66 |
| ENVIRONMENTAL |
| Operating Temperature |
0°C – 40°C (32°F – 104°F) |
| Storage Temperature |
-20°C – 60°C (-4°F – 140°F) |
| Humidity |
5% – 90% RH (non-condensing) |
| Ambient Light Injection |
4,500 Lux (fluorescence) |
| Shock |
Designed to withstand 1 m drops |
| DECODING CAPABILITY |
| 1D Barcodes |
UPC/EAN/JAN, UPC/EAN with supplementary, JAN 8 & JAN 13,
ISBN/ISSN, Japanese Bookland EAN, Code 39, Code 39 with full
ASCII, trioptic Code 39, Codabar (NM7), Code 128, Code 128 with full
ASCII, Code 93, Interleaved 2 of 5 (ITF), Addendum 2 of 5, IATA
Code, MSI/Plessy, China Postal Code, Code 32 |
| Options |
Industrial 2 of 5, Standard 2 of 5, Discrete 2 of 5,
Matrix 2 of 5, Code 11, UPC/EAN RSS, RSS variants |
產品規格 (PDF)
